320x132 OLED LCD Modules | BL320132A
● OLED Display 320 x 132 dots
● Built-in controller SSD1320Z *2
● +1.65~ +3.5V single power supply
● 1/132 duty cycle
● Color: white
● SPI Interface
● Built-in controller SSD1320Z *2
● +1.65~ +3.5V single power supply
● 1/132 duty cycle
● Color: white
● SPI Interface
Model :
BL320132A
The module dimension of UL320132A is 145.52 X 41.672 mm and Active Area is 89.90 X 37.072 mm.
It has built-in IC SSD1320Z and it supports SPI interface.
UL320132A required +1.65~ +3.5V single power supply.
As most industrial OLED displays, the BL-series module offers extremely wide operating temperature range of -40 to + 80°C.
UL320132A is 3.83 inch 320X132 dots Graphic OLED Display Modules.
It has built-in IC SSD1320Z and it supports SPI interface.
UL320132A required +1.65~ +3.5V single power supply.
As most industrial OLED displays, the BL-series module offers extremely wide operating temperature range of -40 to + 80°C.
UL320132A is 3.83 inch 320X132 dots Graphic OLED Display Modules.
