GRAPHIC LCD
Graphic LCD is meant to display images, letters and numbers.
For example, a 128 x 64 LCD would contain 128 horizontal dots and 64 Vertical dots. Each of these dots can be turned ON and OFF independently and are referred as pixel.
UJ Light is a leading manufacturer of Graphic LCD modules (liquid crystal display) in Taiwan.
We offer many standard graphic LCD, including 122x32, 128x64, 128x128, 144x32, 160x128, 160x160, 160x32, 160x80, 192x64, 192x128, 240x64, 320x240 and also provide customized LCD.
UJ Light have various color LCD display with different LED backlights. Yellow-Green LCD module, White LCD Module, Red LCD Module etc. please refer to our LCD shade card for more details.
We cater to customers across the globe and offer graphic LCD for various applications; white goods LCD, POS system LCD, industrial LCD, automotive LCD, medical LCD, defense LCD and many more.
Different application require different LCD view angles and UJ Light offers viewing angles of 6:00, 12:00, 3:00, and 9:00 o'clock.
Display Format
Model No.
Outline Dimension (mm)
View Area (mm)
Active Area (mm)
Duty
Interface
IC Part No. or Compatible with
Controller
122x32
84x44
60x18
53.64x15.64
1/32
Parallel
122x32
84x44
60x18
53.64x15.64
1/32
Parallel
122x32
65.8x27.1
60.5x18.5
53.64x15.64
1/32
Parallel
122x32
80x36
60x18
53.64x15.64
1/32
Parallel
122x32
80x36
60x18
53.64x15.64
1/32
Parallel
122x32
68x26.8
61x19
56.08x16.28
1/32
Parallel
98x32
52x44
46x18.5
43.08x15.64
1/32
Parallel
128x64
93x70
72x40
66.52x33.24
1/64
Parallel
128x64
93x70
72x40
66.52x33.24
1/64
Parallel
128x64
93x70
72x40
66.52x33.24
1/32
Parallel/SPI
128x64
80x70
72x40
66.52x33.24
1/64
Parallel
128x64
78x70
62x44
56.3x38.38
1/64
Parallel
128x64
78x70
62x44
56.3x38.38
1/64
Parallel
128x64
75x52.7
60x32.6
55x27.48
1/64
Parallel
128x64
87x70
72x40
66.52x33.24
1/64
Parallel
128x64
54x50
43.5x29
40.92x26.92
1/64
Parallel
160x32
116x37
85x18.6
79.95x15.95
1/64
Parallel/SPI
160x80
100x54
72.3x37.8
67.17x33.5
1/80
Parallel
160x112
94x80
74x54
68.77x48.13
1/112
Parallel
129x102
101x82
92.76x74.22
1/128
Parallel
192x64
100x60
84x31
78.67x26.18
1/64
Parallel
240x64
180x65
133x39
127.16x33.88
1/64
Parallel
170x103.5
132x76
119.97x63.97
1/128
Parallel
None
240x128
144x104
114x64
107.98x57.58
1/128
Parallel
240x128
144x104
114x64
107.98x57.58
1/128
Parallel
240x128
170x103.5
132x76
119.97x63.97
1/128
Parallel
166.8x109
122x92
115.18x86.38
1/240
Parallel
None
148x120.24
120.14x92.14
115.18x86.38
1/240
Parallel
166.8x109
122x92
115.18x86.38
1/240
Parallel
160x109
122x92
115.18x86.38
1/240
Parallel
128x64
BG12864J
75x45.8
61x38
56.3x33.26
1/64
Parallel
NT7107/NT7108
128x64 Graphic LCD Display Module | BG12864H
● Built-in controller NT7107/NT7108 or equivalent
● +5V single power supply, with built-in negative voltage
● 1/64 duty cycle
● Option: EL backlight & EL inverter
● Option: +3V single power supply
● Option: external negative voltage
● No LED Backlight Option
320x240 Graphic LCD Display Module | BG320240G
● built-in controller RA8806 +5V single power supply,
with built-in negative voltage
● 1/240 duty cycle
● Option: LED edge/white B/L
● Option: +3V single power supply
● Option: negative voltage
320x240 Graphic LCD Display Module | BG320240F
● Built-in controller RA8835
● +5V single power supply
● 1/240 duty cycle
● Option: LED edge B/L, CCFL
● Option: +3V single power supply
● Option: negative voltage (built-in, external)
● Option: touch panel
320x240 Graphic LCD Display Module | BG320240B1
● Built-in controller RA8835
● +5V power supply
● 1/240 duty cycle
● Option: LED edge/white B/L, CCFL
● Option: negative voltage (built-in, external)
● Option: touch panel
● Option: 80 Series MPU interfance
● Option: +3V single power supply
320x240 Graphic LCD Display Module | BG320240A
● No controller,recommending RA8835
● +5V single power supply
● 1/240 duty cycle
● Option: negative voltage
● Option: LED edge B/L, CCFL
● Option: +3V single power supply
● Option: negative voltage (built-in, external)
● Option: touch panel
240x128 Graphic LCD Display Module | BG240128BA
● Built-in controller UCi6963c
● 1/128 duty cycle
● +5V single power supply
● Option: negative voltage
● Option: LED edge/array B/L
240x128 Graphic LCD Display Module | BG240128B2
● Built-in controller UCi6963c or equivalent
● 1/128 duty cycle
● +5V single power supply
● Option: negative voltage
● Option: temperature compensation
● Option: LED array/edge B/L,EL B/L, CCFL
240x128 Graphic LCD Display Module | BG240128A
● Built-in controller UCi6963c or equivalent
● 1/128 duty cycle
● Option: negative voltage
● Option: LED Green, white B/L,EL B/L,CCFL
240x64 Graphic LCD Display Module | BG24064A
● Built in controller UCi6963c or equivalent
● +5V power supply
● 1/64 duty
● LED B/L pins: A / K
● Option: Temperature compensation
● Option: LED, EL B/L
● Option: External negative voltage(built-in, extemal)
